PROPOSED 5 BEDROOM DUPLEX DELTA STATE RF NO; {5347BD}

by Dioritestructures

5 BEDROOM DUPLEX WITH PENT HOUSE

PLOT SIZE; 1,064 sqm  {11,822 sqft}

LOCATION: Delta State, Nigeria 🇳🇬

DESIGNED AND VISUALIZED by: Dioritestructures Ltd

SPACE ALLOCATION AND DESCRIPTION.

MINIMUM LAND SIZE; 750 sqm ~ 8,333 sqft

BUILDING AREA; 235.14 Sqm ~ 2,613 Sqft

LENGTH ❌ BREADTH; 21,850 mm by 11,350 mm

BUILDING HEADROOM; 3,600 mm {12 ft} Floor to Ceiling

NUMBER OF LOUNGES; 4 {FOUR}

NUMBER OF ROOMS;      5 {FIVE}

NUMBER OF RESTROOM;  7 {SEVEN}

NUMBER OF FLOORS;        3 {THREE}

NUMBER OF STAIRWAY; 2 {TWO} A STRINGER STEEL FLOATING STAIRWAY WITH POLISHED HARDWOOD FOR THE THREADS AT THE MAIN LOUNGE + A HIDDEN REINFORCED QUARTER TURN STAIRWAY BETWEEN THE DINING AND THE KITCHEN.

ROUGH ESTIMATE (COST/CARCASS; FOUNDATION TO ROOFING); NIL {without finishing & furnishing}

_____________________________________________________________
𝐏𝐋𝐀𝐍 𝐃𝐄𝐒𝐂𝐑𝐈𝐏𝐓𝐈𝐎𝐍 {𝐒𝐔𝐌𝐌𝐀𝐑𝐘}

A stunning unique 5 bedroom duplex with pent house with modern and traditional concept, that combines elegance, simplicity, luxury and flexibility to adapt to the different needs of the client.

This masterpiece comes with some amazing features such as;

* Well lit and integrated
* Wide window for daylight, ventilation and aesthetics
*High quality finishes
*Modern and versatile kitchen
*Spacious rooms with flexible use possibilities

SPACIAL ANALYSIS

Master’s bedroom; 46sqm of space || Master’s Closet; 14sqm. || Master’s Restroom; 16sqm

Anteroom; 22sqm. ||. Main Lounge; 49sqm || Dining; 14sqm. ||. Kitchen; 35sqm

Guest Bedroom; 17sqm || Bedroom 2; 35sqm. || Bedroom 3; 28sqm ||. Private Master’s bedroom at the pent; 50sqm

Family Lounge; 41sqm. ||. Home Office; 14sqm. ||. Private Lounge; 40sqm. ||. Open Patio at the front; 33sqm || Outdoor Living Area at the pent floor; 83sqm

                               PLAN DETAILS

Stories/Floors; 3

Bedrooms; 5 all ensuite

Restroom/Toilet; 7

Lounges/Living room; 4

Dining; 1

Enclosed Kitchen; 1

Store/pantry; 1

Open sitout; 3

General Parking; 6+ Cars

                         DRAWING PACKAGES

BRONZE PACKAGE || GOLD PACKAGE || PREMIUM PACKAGE

PRICES DIFFER PER PACKAGE BUT ALL COME WITH THESE COMMON DOCUMENTS.

Site Plan

Foundation Layout Plan

Floor Plans

Roof Plans

Sections

Elevations

Construction Details

Doors and Windows Schedule

Floor Finishes and Furniture Layout Plans

Soak away and Septic tank details

Schematic details

Structural Drawings, Mechanical Drawings and Electrical Drawings depends on the package you’re interested in

Drawings delivered in PDF format via mail for Foreign Buyers and Clients.

For buyers and clients within Nigeria, drawings delivered in PDF format via mail, hardcopy delivery with ARCON AND COREN stamp depending on what you want all to be delivered to your respective states.

For your Building Plans and Construction works kindly reach out to us via

Call/WhatsApp: 0810 045 2977 or 0812 716 7275

Mail: info@dioritestructures.com.ng OR. dioritestructures@gmail.com

WEBSITE: www.dioritestructures.com.ng
